Signal Management
Relocate your antenna from the radio body to plate-carrier webbing or a remote mast. Clears workspace, reduces snag risk, and keeps LMR-195-UF performance for tactical radios.
KIT
Complete kit (cable + SMA adapters + pouch)
Same BNC M to BNC M ultra-flexible LMR-195-UF relocation cable as our standard BNC run — packaged as a full kit so you have everything needed to relocate the standard-issue antenna on Motorola APX and a wide range of public-safety and commercial off-the-shelf (COTS) radios that use SMA antenna ports.
Included:
-
1× BNC male to BNC male LMR-195-UF relocation cable (length selected below)
-
1× BNC F to SMA M adapter (radio / antenna path)
-
1× BNC F to SMA F adapter (radio / antenna path)
-
1× Raptor Athena antenna relocation pouch (color selected below)
Radio Interface: BNC cable + SMA adapter pack
Cable is straight BNC M both ends. The included SMA M and SMA F adapters let you mate that cable to a wide variety of public-safety and COTS radios that use SMA antenna connectors — without buying adapters separately.
SMA-F antenna port radios (typical)
-
Motorola APX series APX 6000 / 7000 / 8000 / NEXT — standard factory antenna relocation
-
Motorola XPR / MOTOTRBO portables SMA antenna-port variants
-
Baofeng UV-5R family UV-5R, UV-5RA, UV-5R V2+, BF-F8HP and similar SMA-F HTs
-
Baofeng UV-82 / GT-3 / similar COTS HTs when the radio uses an SMA antenna port
-
Wouxun, TYT, Retevis & other SMA HTs commercial / amateur portables with SMA-F or SMA-M antenna ports
-
Other public-safety & commercial SMA radios confirm antenna port gender (SMA-F vs SMA-M) before ordering
Both SMA M and SMA F adapters ship in the kit so you can orient radio-side and antenna-side as needed. Not for TNC mil / QD-only radios without additional adapters.
Cable Performance
-
LMR-195-UF ultra-flexible low-loss coax
-
BNC male to BNC male (straight both ends)
-
~0.09 dB loss per foot class (field length dependent)
-
MOLLE-friendly routing without kinking
-
Pairs with DISCO32 blade antennas & VMAS
Connector Check
This listing is the ARK-APX complete kit: BNC M to BNC M LMR-195-UF cable plus SMA M / SMA F adapter pack plus Raptor pouch. Same cable family as our stand-alone BNC straight relocation cable. Confirm your radio antenna port (SMA gender) before ordering. Wrong connector family will not mate without the correct adapters.
Warranty
DISCO32 limited warranty — 1 year from original purchase for defects in materials and workmanship under normal use. Support starts with a troubleshooting ticket at help@disco32.com.
